-23%
Radiador
Radiador Aluminio con Enfriador de Aceite 48mm – TCM
Bodega:
2 disponibles
Grúa Horquilla: TCM 48 mm Aluminio c/n Enfriador de aceite
Modelo: FG/D20-30T6,K21. FG/D20-30T3,TD2. FD20-30V5T,CA498 /FD20-30T3CD,CA498 /FD30T3CD-A,V2403FD20-30T4 /FD20-30T4C
Código: CA01-J21
Para ver los precios, Inicia sesión o Regístrate
- Radiator type: vertical
- Position radiator cap: L2
- Position of input water connection: R
- Outer diameter of the input water connection D1 (mm): 35.5
- Position of output water connection: L
- Outer diameter of the output water connection D2 (mm): 35.5
- Center distance between input and output water connection L3 (mm): 655
- Position draincock: 20
- Length without accessories or mounting plates L1 (mm): 633
- Height without accessories or mounting plates H1 (mm): 450
- Width without accessories or mounting plates W1 (mm): 90
- Total length with accessories or mounting plates L2 (mm): 700
- Total height with accessories or mounting plates H2 (mm): 470
- Total width with accessories or mounting plates W2 (mm): 138
- Position oil cooler: K2
- Center distance between the 2 connections of the oil cooler L4 (mm): 275
- Thickness of core of the radiator W3 (mm): 49
- Center distance of the fins L5 (mm): 10.5
- Material collector: plastic
- Material core: aluminium
- Equipment market EQ-M: material handling parts
- Peso (kg): 11.2
