Radiador
Radiador Aluminio con Enfriador de Aceite 48mm – Toyota
Bodega:
2 disponibles
Grúa Horquilla: Toyota 48 mm Aluminio c/n Enfriador de aceite
Modelo: Toy. 2Z,4Y/8FD/G20-25, 1DZ,2Z/7-8FD20-25,4Y,5K/7FG20-25
Código: CA01-J12
Para ver los precios, Inicia sesión o Regístrate
- Radiator type: vertical
- Position radiator cap: R2
- Position of input water connection: L
- Outer diameter of the input water connection D1 (mm): 36.5
- Position of output water connection: R
- Outer diameter of the output water connection D2 (mm): 36.5
- Center distance between input and output water connection L3 (mm): 655
- Position draincock: 38
- Length without accessories or mounting plates L1 (mm): 630
- Height without accessories or mounting plates H1 (mm): 455
- Width without accessories or mounting plates W1 (mm): 62
- Total length with accessories or mounting plates L2 (mm): 700
- Total height with accessories or mounting plates H2 (mm): 470
- Total width with accessories or mounting plates W2 (mm): 130
- Position oil cooler: K4
- Center distance between the 2 connections of the oil cooler L4 (mm): 275
- Thickness of core of the radiator W3 (mm): 36
- Center distance of the fins L5 (mm): 10
- Peso (kg): 7.3
