Protege tu motor Komatsu con nuestro radiador de 48mm. Un repuesto esencial con enfriador de aceite integrado que garantiza el rendimiento de tu grúa horquilla. ¡Envío rápido a todo Chile!
Radiator type: vertical
Position radiator cap: L2
Position of input water connection: R
Outer diameter of the input water connection D1 (mm): 36
Position of output water connection: L
Outer diameter of the output water connection D2 (mm): 36
Center distance between input and output water connection L3 (mm): 660
Position draincock: 23
Length without accessories or mounting plates L1 (mm): 630
Height without accessories or mounting plates H1 (mm): 460
Width without accessories or mounting plates W1 (mm): 80
Total length with accessories or mounting plates L2 (mm): 700
Total height with accessories or mounting plates H2 (mm): 492
Total width with accessories or mounting plates W2 (mm): 140
Position oil cooler: K3
Center distance between the 2 connections of the oil cooler L4 (mm): 205
