Radiador
Radiador Aluminio con Enfriador de Aceite 48mm – Heli
Bodega:
1 disponibles
Grúa Horquilla: Heli 48 mm Aluminio c/n Enfriador de aceite
Modelo: HELI H2000 Series K21,K25/. CPQD-20-35,G Series K21,K25,H25/. CPQD20-30
Código: CA01-J11
Para ver los precios, Inicia sesión o Regístrate
- Radiator type: vertical
- Position radiator cap: L5
- Position of input water connection: R
- Outer diameter of the input water connection D1 (mm): 36
- Position of output water connection: L
- Outer diameter of the output water connection D2 (mm): 36
- Center distance between input and output water connection L3 (mm): 680
- Position draincock: 22
- Length without accessories or mounting plates L1 (mm): 635
- Height without accessories or mounting plates H1 (mm): 435
- Width without accessories or mounting plates W1 (mm): 98
- Total length with accessories or mounting plates L2 (mm): 700
- Total height with accessories or mounting plates H2 (mm): 618
- Total width with accessories or mounting plates W2 (mm): 257
- Position oil cooler: K2
- Center distance between the 2 connections of the oil cooler L4 (mm): 250
- Thickness of core of the radiator W3 (mm): 56
- Center distance of the fins L5 (mm): 11.5
- Diameter of the wind tunnel D3 (mm): 437
- Length of the core of the radiator L6 (mm): 505
- Height of the core of the radiator H3 (mm): 425
- Peso (kg): 17.53
