- Radiator type: vertical
- Position radiator cap: R2
- Position of input water connection: L
- Outer diameter of the input water connection D1 (mm): 36.5
- Position of output water connectionR
- Outer diameter of the output water connection D2 (mm): 36.5
- Center distance between input and output water connection L3 (mm): 695
- Position draincock: 40
- Length without accessories or mounting plates L1 (mm): 635
- Height without accessories or mounting plates H1 (mm): 470
- Width without accessories or mounting plates W1 (mm): 75
- Total length with accessories or mounting plates L2 (mm): 700
- Total height with accessories or mounting plates H2 (mm): 485
- Total width with accessories or mounting plates W2 (mm): 110
- Position oil cooler: without
- Thickness of core of the radiator W3 (mm): 48
- Center distance of the fins L5 (mm): 8
- Equipment market EQ-M: material handling parts
- Peso (kg): 10.7
Radiador
Radiador Aluminio con Enfriador de Aceite 48mm – Komatsu
Bodega:
3 disponibles
Grúa Horquilla: Komatsu 48 mm Aluminio sin Enfriador de aceite
Modelo: Kom. 4D92E/FD15C20, 4D94LE/FD20/30-16(700001-744499)
Código: CA01-J16
Para ver los precios, Inicia sesión o Regístrate
| Marca |
|---|
