Radiador
Radiador Aluminio con Enfriador de Aceite 48mm – Toyota
Bodega:
2 disponibles
Grúa Horquilla: Toyota 48 mm Aluminio c/n Enfriador de aceite
Modelo: FDZN20-30/1DZ, FGZN20-30/4Y, 8FDK20-30/1DZ, 8FGK20-30/4Y
Código: CA01-J14
Para ver los precios, Inicia sesión o Regístrate
- Radiator type: vertical
- Position radiator cap: R5
- Position of input water connection: L
- Outer diameter of the input water connection D1 (mm): 34
- Position of output water connection: R
- Outer diameter of the output water connection D2 (mm): 34
- Center distance between input and output water connection L3 (mm): 630
- Position draincock: 38
- Length without accessories or mounting plates L1 (mm): 560
- Height without accessories or mounting plates H1 (mm): 470
- Width without accessories or mounting plates W1 (mm): 73
- Total length with accessories or mounting plates L2 (mm): 628
- Total height with accessories or mounting plates H2 (mm): 493
- Total width with accessories or mounting plates W2 (mm): 147
- Position oil cooler: K3
- Center distance between the 2 connections of the oil cooler L4 (mm): 255
- Thickness of core of the radiator W3 (mm): 48
- Center distance of the fins L5 (mm): 10
- Length of the core of the radiator L6 (mm): 455
- Height of the core of the radiator H3 (mm): 450
- Material collector: plastic
- Material core: aluminium
- Equipment market EQ-M: material handling parts
- Peso (kg): 9.015
